Product Introduction
Shenzhen Suosheng Technology Co., Ltd. acts as an agent for American Comus mercury tilt angle switches, Comus mercury tilt angle switches, Comus mercury tilt angle switches, Comus mercury tilt angle switches, Comus spring switches, Comus mercury switches, Comus proximity switches, Comus capacitive sensors, Comus impact switches, Comus vibration switches, Comus float switches, Comus emergency switches, Comus high-voltage * * relays, Comus mercury * * relays, Comus solid-state relays, etc.
The main models are: CM100-0、CM200-0、CM100-70、CM200-70、CM225-0、CM225-70、CM265-0、CM1000-0、CM1000-90、CM1000-70、CM1020-0、CM1050-0、CM1220-0、CM1230-0、CM1320-0、CM1320-70、CM1320-90、CM2000-0、CM2000-70、CM2050-0、CM1365-0、CM1350-1、CM1370-0、CM1370-1
Tilt/Tip-Over Switches - Mercury
|
CM100-0
|
Switching Voltage: 120Vac Max.
Switching Current: 1.0A Max.
Switching Capacity: 120VA Max.
Differential Angle: 10° Max.
Contact Resistance: 3 Ohms Max.
Size: Over All Length: 0.813in (20.65mm)
Diameter: 0.322in (8.19mm)
Electrode Diameter: 0.040in (1.0mm)
Tilt Switch
|
|
|
|
CM200-0
|
Switching Voltage: 120Vac Max.
Switching Current: 2.0A Max.
Switching Capacity: 240VA Max.
Differential Angle: 10° Max.
Contact Resistance: 3 Ohms Max.
Size: Over All Length: 1.09in (27.68mm)
Diameter: 0.322in (8.18mm)
Electrode Diameter: 0.040in (1.0mm)
Tilt Switch - 1 Electrode - High Power
|
|
|
|
CM100-70
|
Switching Voltage: 120Vac Max.
Switching Current: 1.0A Max.
Switching Capacity: 50VA Max.
Differential Angle: 10° Max.
Contact Resistance: 3.0 Ohms Max.
Size: Over All Length: 1.3in (33.0mm)
Diameter: 0.5in (12.7mm)
Leadwire Length: 6.5in (165.1mm)
Encapsulated Tilt Switch
|
|
|
|
CM200-70
|
Switching Voltage: 120Vac Max.
Switching Current: 2.0A Max.
Switching Capacity: 100VA Max.
Differential Angle: 8° Max.
Contact Resistance: 3.0 Ohms Max.
Size: Over All Length: 1.3in (33.0mm)
Diameter: 0.5in (12.7mm)
Leadwire Length: 7.0in (177.8mm)
Encapsulated Tilt Switch
|
|
|
|
CM225-0
|
Switching Voltage: 120Vac Max.
Switching Current: 2.0A Max.
Switching Capacity: 240VA Max.
Differential Angle: 25° Max.
Contact Resistance: 3 Ohms Max.
Size: Over All Length: 1.10in (27.94mm)
Diameter: 0.322in (8.18mm)
Electrode Diameter: 0.040in (1.0mm)
Tilt Switch - 1 Electrode - High Power
|
|
|
|
CM225-70
|
Contact Resistance: 3.0 Ohms Max.
Switching Voltage: 240 Vac Max.
Switching Current: 1.5 at 240 Vac / 2.0 at 120 Vac
Differential Angle: 25° Deg.
Size: L: 33.0mm (1.299in) Dia: 12.7mm (.500in)
Tilt Switch
|
|
|
|
CM265-0
|
Switching Voltage: 120Vac Max.
Switching Current: 2.0A Max.
Switching Capacity: 240VA Max.
Differential Angle: 65° Max.
Contact Resistance: 3 Ohms Max.
Size: Over All Length: 1.09in (27.68mm)
Diameter: 0.322in (8.18mm)
Electrode Diameter: 0.040in (1.0mm)
Tilt Switch - 1 Electrode - High Power
|
|
|
|
CM1000-0
|
Switching Voltage: 120Vac Max.
Switching Current: 10.0A Max.
Switching Capacity: 1200VA Max.
Differential Angle: 10° Max.
Contact Resistance: 3 Ohms Max.
Size: Over All Length: 1.50in (38.10mm)
Diameter: 0.440in (11.1mm)
Electrode Diameter: 0.093in (2.4mm)
Tilt Switch - 1 Electrode - High Power
|
|
|
|
CM1000-90
|
Switching Voltage: 120Vac Max.
Switching Current: 10.0A Max.
Switching Capacity: 1200VA Max.
Differential Angle: 10? Max.
Contact Resistance: 3.0 Ohms Max.
Size: L: 1.90in (48.26mm)
H: 1.100in (27.94mm)
W: 0.580in (14.73mm)
Leadwire Length: 7.0in (177.8mm)
Encapsulated Tilt Switch
|
|
|
|
CM1000-70
|
Switching Voltage: 120Vac Max.
Switching Current: 10A Max.
Switching Capacity: 1200VA Max.
Differential Angle: 10° Max.
Contact Resistance: 5.0 Ohms Max.
Size: Over All Length: 1.875in (47.62mm) Diameter: 0.53in (13.46mm)
Leadwire Length: 7.0in (177.80mm) Encapsulated Compact Tilt Switch
|
|
|
|
CM1020-0
|
Switching Voltage: 120Vac Max.
Switching Current: 10.0A Max.
Switching Capacity: 1200VA Max.
Differential Angle: 15° Max.
Contact Resistance: 3 Ohms Max.
Size: Over All Length: 1.725in (43.81mm)
Diameter: 0.435in (11.05mm)
Electrode Diameter: 0.094in (2.39mm)
Tilt Switch - 1 Electrode - High Power
Break Before Make
|
|
|
|
CM1050-0
|
Switching Voltage: 120Vac Max.
Switching Current: 10.0A Max.
Switching Capacity: 1200VA Max.
Differential Angle: 15° Max.
Contact Resistance: 3 Ohms Max.
Size: Over All Length: 1.725in (43.81mm)
Diameter: 0.435in (11.05mm)
Electrode Diameter: 0.094in (2.39mm)
Tilt Switch - 1 Electrode - High Power
Make Before Break
|
|
|
|
CM1220-0
|
Switching Voltage: 120Vac Max.
Switching Current: 0.20A Max.
Switching Capacity: 30VA Max.
Differential Angle: 10° Max.
Contact Resistance: 1.0 Ohms Max.
Size: Over All Length: 0.760in (19.30mm)
Diameter: 0.222in (5.64mm)
Electrode Diameter: 0.018in (0.46mm)
Electrode Spacing: 0.060in (1.52mm)
Tilt Switch - General Purpose
|
|
|
|
CM1230-0
|
Switching Voltage: 120Vac Max.
Switching Current: 0.20A Max.
Switching Capacity: 30VA Max.
Differential Angle: 10° Max.
Contact Resistance: 3.0 Ohms Max.
Size: Over All Length: 0.580in (14.7mm)
Diameter: 0.222in (5.64mm)
Electrode Diameter: 0.020in (0.51mm)
Tilt Switch - 1 Electrode - Short Body
|
|
|
|
CM1320-0
|
Switching Voltage: 120Vac Max.
Switching Current: 0.2** Max.
Switching Capacity: 30VA Max.
Differential Angle: 10° Max.
Contact Resistance: 1.0 Ohms Max.
Size: Over All Length: 1.075in (27.3mm)
Diameter: 0.185in (4.7mm)
Electrode Diameter: 0.018in (0.46mm)
Electrode Spacing: 0.050in (1.27mm)
Tilt Switch - General Purpose
|
|
|
|
CM1320-70
|
Switching Voltage: 120Vac Max.
Switching Current: 0.2** Max.
Switching Capacity: 30VA Max.
Differential Angle: 20° Max.
Contact Resistance: 1.0 Ohms Max.
Size: Over All Length: .930in (23.62mm) Diameter: 0.366in (9.30mm)
Leadwire Length: 7.0in (177.80mm) Encapsulated Compact Tilt Switch
|
|
|
|
CM1320-90
|
Switching Voltage: 120Vac Max.
Switching Current: 0.2** Max.
Switching Capacity: 30VA Max.
Differential Angle: 10° Max.
Contact Resistance: 1.0 Ohms Max.
Size: L: 1.85in (47.0mm)
H: 0.472in (12.0mm)
W: 0.443in (11.0mm)
Leadwire Length: 10.0in (254.0mm)
Encapsulated Tilt Switch
(See S1039)
|
|
|
|
CM2000-0
|
Switching Voltage: 120Vac Max.
Switching Current: 20.0A Max.
Switching Capacity: 2400VA Max.
Differential Angle: 10° Max.
Contact Resistance: 3.0 Ohms Max.
Size: Over All Length: 1.50in (38.1mm)
Diameter: 0.625in (15.875mm)
Electrode Diameter: 0.156in (3.96mm)
Tilt Switch - 1 Electrode - High Power
|
|
|
|
CM2000-70
|
Contact Resistance: 3.0 Ohms Max.
Switching Voltage: 240 Vac Max.
Switching Current: 10 at 240 Vac / 20 at 240 Vac
Differential Angle: 10° Max.
Size: L: 51.0mm (2in) Dia: 19.0mm (.748in)
Tilt Switch
|
|
|
|
CM2050-0
|
Switching Voltage: 120Vac Max.
Switching Current: 20.0A Max.
Switching Capacity: 2400VA Max.
Differential Angle: 10° Max.
Contact Resistance: 3.0 Ohms Max.
Size: Over All Length: 1.740in (44.19mm)
Diameter: 0.625in (15.875mm)
Electrode Diameter: 0.156in (3.96mm)
Tilt Switch - High Power - Make Before Break
|
|
|
|
CM1365-0
|
Switching Voltage: 120Vac Max.
Switching Current: 0.2** Max.
Switching Capacity: N/A
Operating Angle: 60°± 15°
Contact Resistance: 3.0 Ohms Max.
Size: Over All Length: .870in (22.1mm)
Diameter: 0.185in (4.7mm)
Electrode Diameter: 0.018in (0.46mm)
Electrode Spacing: 0.050in (1.27mm)
Tip-Over Switch - General Purpose - Miniature
|
|
|
|
CM1350-1
|
Switching Voltage: 120Vac Max.
Switching Current: 0.** Max.
Switching Capacity: 50VA Max.
Operating Angle: 50°± 15°
Contact Resistance: 3.0 Ohms Max.
Size: Over All Length: .670in (17.0mm)
Diameter: 0.185in (4.7mm)
Electrode Diameter: 0.018in (0.46mm)
Electrode Spacing: 0.116in (2.79mm)
Tip-Over Switch - General Purpose - Omnidirectional
|
|
|
|
CM1370-0
|
Switching Voltage: 120Vac Max.
Switching Current: 0.2** Max.
Switching Capacity: 60VA Max.
Operating Angle: 60°± 10°
Contact Resistance: 3.0 Ohms Max.
Size: Over All Length: .665in (16.89mm)
Diameter: 0.185in (4.7mm)
Electrode Diameter: 0.040in (1.016mm)
Tip-Over Switch - General Purpose
Omnidirectional
|
|
|
|
CM1370-1
|
Switching Voltage: 120Vac Max.
Switching Current: 0.2** Max.
Switching Capacity: 60VA Max.
Operating Angle: 60°± 10°
Contact Resistance: 3.0 Ohms Max.
Size: Over All Length: .665in (16.89mm)
Diameter: 0.185in (4.7mm)
Electrode Diameter: 0.040in (1.016mm)
Electrode Spacing: 0.111in (2.82mm)
Tip-Over Switch - General Purpose
Omnidirectional
|
|
|
|
