2. Save labor costs: If equipped with a three-axis servo robotic arm, each machine can reduce 2 employees, effectively reducing personnel wages and management costs.

3. Enhancement of mold locking force by 10 times: Using the principle of electro-hydraulic cylinder, the closed-loop hydraulic mold locking force is enhanced by 10 times compared to ordinary models.

4. Accurate and fast mold transfer: The swing frame is driven by a servo motor, which accelerates quickly in an instant, brakes accurately, and can adjust the speed of mold transfer.

5. The pure electric drive plug pen has a faster response speed and smooth movement.

6. Meet high hygiene standards: Pure electric drive is more suitable for products with extremely strict hygiene requirements such as food, medicine, and beverages.

7. Multiple utility model patents are applied to this product.

1. Equipped with servo motor driven molds, electric pens, electric swing frames, and other servo motor drives, it is very energy-efficient.

2. Using a highly reliable and stable industrial computer (with touch screen) to control actions and temperature (with PID function).

3. The insertion movement of the pen can be adjusted by manipulating the screen numbers, without the need for manual mechanical adjustment.

4. The mechanical structure using servo motors and ball screws instead of the original hydraulic cylinder and displacement sensor has the characteristics of high motion accuracy, light and agile motion, and fast response speed.

5. Equipped with an electric lifting platform and a water outlet material device.

6. Using well-known pneumatic, hydraulic, and electrical control components, with a long service life.

7. Optional automatic feeding device and product conveying device for easy assembly line production.

8. The extrusion motor adopts variable frequency speed regulation, which can adapt to the requirements of screw speed changes in blow molding process.

9. The model is equipped with a thickness control function, which is very precise in controlling the thickness of the bottle wall.

1. For the convenience of material return, users can choose to add hydraulic automatic filter screen replacement devices, which can include downward blowing, wall thickness controllers, automatic cutting bottom pulling or automatic trimming devices;

2. Optional pre sealed cutting knife, horizontal cutting knife, imported hot cutting knife, cold cutting knife, etc;

3. Optional options include oblique insertion pen, downward insertion pen, blowing needle insertion pen, auxiliary cooler, etc;

4. Optional thickness controller;

5. Optional use of Leshan Machinery's independently developed permanent magnet brushless DC motor for plastic hollow forming machines: high reliability, good stability, and comprehensive energy saving of 8% to 15%;

6. Optional polymer mixture screw: ensuring product performance while saving 15% -30% of raw materials;

7. Optional Austrian SIGMATEK control system, which executes commands ten times faster than traditional cyclic refresh mode;

8. Optional remote after-sales service system: automatic fault analysis and diagnosis, maintenance records, report statistics, video transmission, remote mobile SMS notifications and alarms, etc., all in one hand, with a clear understanding;

9. Optional dust-free air supply system, conveyor belt, automatic feeding system, 4-in-1 feeding machine and other supporting functions;

10. Optional functions include mold ejector pin, in mold labeling, online leak detection, and lid opening and closing;

11. Optional front and rear mobile platforms for convenient mold installation;

12. Optional pre clamping function, 2-axis servo manipulator, and single axis servo manipulator;

13. Users can choose from split shuttle, spiral or rubber extrusion die, continuous extrusion die, and storage die according to their preferences.

14. Optional with a super large pen blowing function to quickly increase production.

15. Optional robotic arm, combined with secondary blowing and sizing, blowing and leak detection functions.

16. Optional gong mouth machine (internal or external) can meet the requirements of different product sizes, making the bottle mouth smoother.

1.1 Check whether the machine has any damaged parts or components, whether the screws are loose, and whether the wires and cables are damaged or detached. If there is any damage, it should be replaced or repaired in a timely manner; Check for debris in the extruder hopper and clean it thoroughly, then close the material gate.

1.2 Check whether the moving parts are firm, whether the screws are loose or detached, especially in areas with strong impact, and whether the belt transmission part is abnormal.

1.3 Check whether the high-pressure gas source, low-pressure gas source, power supply, and water source are normal.

1.4 Check if all emergency stop switches, safety door switches, and protection device detection switches are functioning properly.

1.5 Check whether each pneumatic component leaks air and whether the action is sensitive.

1.6 Please strictly follow the procedures in the operation manual.

When the machine is in normal production, there needs to be a dedicated person responsible for monitoring and promptly handling any problems found. Due to the high degree of machine automation, the workload during normal production is minimal. Users only need to add raw materials at regular intervals and use containers to collect products and scraps at designated locations on the machine.

Note: The price of the device may change due to its configuration and functionality. For more details, please consult the Leshan Marketing Center.
