(English name: CLEAN BOOTH) Chinese nameAlso known as purification laminar flow shed or dust-free work boothIt is mainly a simple clean room designed for quick and convenient construction. The clean room has multiple cleanliness levels and space combinations that can be designed and manufactured according to usage needs. Therefore, its main characteristics are simple use, high flexibility, easy installation, short construction period, and portability. The clean room can also be locally added to areas that require high cleanliness in general grade clean rooms to reduce costs. A clean room is an air purification device that can provide a locally high cleanliness environment. The clean room is mainly composed of a box, a fan, a primary air filter, a damping layer, lighting fixtures, etc., and the outer shell is sprayed with plastic. This product can be hung or supported on the ground, with a compact structure and easy to use. It can be used individually or connected in multiple ways to form a belt shaped clean area.

CLEAN BOOTHUsing industrial aluminum (or stainless steel square tube, iron square tube spray) as the frame, the fan filter unit (FFU) supplies air, and anti-static curtains (or tempered glass) are hung around, with an internal purification level of 100-10000. Suitable for areas with high local purification requirements within the operating zone.

General configuration of clean room:

1. Framework: Industrial aluminum (or stainless steel square tube, iron square tube spray) is used as the frame to ensure stability, aesthetics, rust resistance, and dust-free properties;

2. Anti static curtains: Anti static curtains (or tempered glass) are used around the perimeter, which have good anti-static effect, high transparency, clear grid, good flexibility, no deformation, and are not easily aged;

3. Fan filter unit FFU: It adopts a centrifugal fan, which has the characteristics of long service life, low noise, maintenance free, low vibration, and stepless speed change. The fan quality is reliable, the working life is long, and the unique air duct design greatly improves the efficiency of the fan and reduces noise! The internal purification level can reach 100-100K level; Especially suitable for areas with high local purification requirements in the workshop, such as assembly line operation areas.

4. The interior adopts a dedicated purification lamp for the purification room, which does not produce dust;

Characteristics of cleanroom products:　

The fan sucks in air from the top of the FFU, passes through the primary filter and high-efficiency filter, and the filtered clean air is uniformly sent out to the clean room at a speed of 0.45m/s ± 20% on the entire air outlet surface. Forming a uniform flow layer ensures a vertical unidirectional flow of clean air, thereby guaranteeing the required cleanliness within the workspace.

A clean room is a simple clean room that can be quickly assembled. It has the characteristics of fast installation, short construction period, low price, and easy mobility. Controlling the main production processes in a smaller environment is also a good choice for clean room design.

Advantages of Clean Room:

1. It can be used alone or in combination.

Compared with civil or prefabricated cleanrooms, Class 100 cleanrooms have lower investment, faster results, easier installation, and lower operating costs.

3. Modular structure, easy to improve cleanliness level, strong scalability, and high reuse value

4. Easy to move (universal wheels can be installed)

How to choose a clean room?
A large number of customers will choose Class 1000 or Class 10000 cleanrooms, while a small number of customers will choose Class 100 cleanrooms;
The choice of cleanroom level depends on the customer's need for cleanliness, but because cleanrooms are relatively enclosed, if a lower cleanroom level is chosen, it is necessary to consider whether employees will feel stuffy and hot inside the cleanroom.

What are the differences between clean rooms, dust-free workshops, and clean workbenches?
Overall, most customers will build a cleanroom inside a cleanroom, but some customers do not want to build a separate cleanroom. Without considering air conditioning systems, air shower rooms, transfer windows, and other purification equipment, the cost of a cleanroom is about 40% to 60% of the cleanroom cost, depending on the customer's choice of cleanroom materials and the size of the cleanroom. The larger the area that needs to be cleaned, the smaller the cost difference between a cleanroom and a dust-free workshop. Compared to clean workbenches, the available effective space inside is larger, and the operation is simple and flexible.
