BK-1C column type force/weight sensor
BK-1C column type force/weight sensor · The elastic body has column, cylinder, and column ring structures, which are used for measuring tensile and co
Product details
·Fully sealed structure, wide range of measurement, stable and reliable performance, easy installation and use.
·Tension compression bearing.
·Industrial automation measurement and control systems suitable for various force/weight measurements.
|
Main technical indicators
|
||||
|
measurement range
|
BK-1C |
0~150 | kN | |
|
Output sensitivity |
1.5～2.0 | mV/V | ||
|
Straightness L |
±0.05; ±0.1 | %F. S | ||
|
Lag H |
±0.05; ±0.1 | %F. S | ||
|
Repetitive R |
±0.05; ±0.1 | %F. S | ||
|
Operating Temperature |
-10～+60 | ℃ | ||
|
Temperature compensation range |
Room temperature~+60 | ℃ | ||
|
Zero temperature influence |
±0.05; ±0.1 | %F. S/10 ℃ | ||
|
Output temperature impact |
±0.05; ±0.1 | %F. S/10 ℃ | ||
|
excitation voltage |
12 | VDC | ||
|
insulation resistance |
2000 | MΩ/100VDC | ||
|
Input resistance: Steel |
380±5/760±5 | Ω | ||
|
aluminum |
400±5/790±5 | Ω | ||
|
output resistance |
350±5/700±5 | Ω | ||
|
Zero point output |
0～±1 | %F. S | ||
|
Safety overload rate |
120 | %F. S | ||
 |
 |
|||||||||||||||||||||||||||||||||||||||||||||||
|
|
Electrical connection method
|
||
|
connection method
|
Plug socket number
|
Wire color
|
| Input (power) positive terminal |
1
|
red
|
| Output signal positive terminal |
2
|
blue
|
| Negative end of output signal |
3
|
white
|
| Input (power) negative terminal |
4
|
Huang
|
| block | / | black |
| If the plug socket number or wire color changes, please refer to the sensor calibration certificate for accuracy. | ||
